Startup work with free Logic template by DAW LibrarY.
Our concept's signal routing of this Logic template is as close to an analog studio mixing console as possible.
This scheme is used to create all of our Logic templates by DAW LibrarY. A diagram of our start-up template's signal routing is included in the readme PDF file.
Several folders with channels for various purposes are created in our Logic template "Startup."
The template has an audio folder - there are about 20 tracks that I specifically left empty and they are intended for recording vocals or acoustic instruments. Audio effects can also be placed on these tracks.
The "Drums" folder can contain a Drum Machine, Quick Sampler, Drum Synth or Sampler, audio channels for individual drum samples, apple loops, and midi tracks for each drum sample. These audio channels are the same as the channels in an analog mixing console - there you can process each drum sound with an equalizer, compressor, and so on. There you can also send the signal to master effects such as reverb, chorus or delay.
Below the "Drums" folder are all the virtual instruments used in our free Logic template "Startup". These tracks combine midi and an audio channel which is all the functions of a normal mixing console audio channel.
Audio Bus Group folder
At the bottom are the "Audio Bus Group" folders. Just like in a studio mixing console, these busses are fed signals from various instruments. For example: all tracks of drums and percussion are fed to drum bus, all guitars to guitar bus and so on. In this folder, there is a bus called master buss, to which all instrumental buses are routed, and the output is connected to „Master Out”. Its purpose is to control the overall volume of the mix before it arrives the “Master Out”.
Master FX folder
The effect channels folder contains all the master send effects (reverb, chorus, delay, etc.). These effect channels can be fed from any virtual instrument or audio track.
Master out folder
All audio busses are connected to the last channel called "Stereo out" or "Master out". This channel is used for final mix processing. It includes all the plugins necessary for mastering (compressor, equalizer, limiter, etc.)
This Logic template contains a track called „Trigger”. This track contains a "rimstick" type sound that beats like a metronome every quarter of a measure. The audio output of this track is muted. This channel serves as a trigger to connect a so-called "sidechannel" to compressors on other audio and instrument tracks as needed. The template includes a short demonstration of signal routing.
